Acute heart failure from a rapidly progressing large tumor in the right atrium

1. Introduction

Intracardiac mass is a rarely encountered phenomenon in the emergency room. An intracardiac mass can be classified into thrombus and non-thrombus. The symptoms caused by a cardiac mass are varied and mimic pulmonary or cardiac conditions depending on the location of the mass rather than the pathology. Our patient presented with a rapid onset of heart failure and was diagnosed with a cardiac mass via computed tomography scan (CT) in the emergency department (ED). For unexplainable cases of heart failure, in-depth radiological studies are recommended to identify the etiology.

2. Case report

A 72-year-old woman with a history of diabetes mellitus and hypertension visited ED with a complaint of dyspnea for about one week. After a series of negative diagnoses on blood exams and electrocardiography, cardiac sonography (Fig. 1) raised suspicions of heart failure (N-terminal pro-B type natriuretic peptide, NT-BNP; 956 pg/mL, normal value $<$125). The patient was discharged with a tentative diagnosis of suspected heart failure.

Fig. 1. Transthoracic echocardiography, four chamber view.

She was sent to the ED again two weeks later for progressed exertional dyspnea associated with dry cough and dizziness. She had no orthopnea, chest pain, or pitting edema, and had not suffered a trauma or undergone operation recently. Her vital signs were normal: body temperature, 36.4 ${}^{\circ }$C; heart rate, 76 beats/min; respiratory rate, 24 times/min; blood pressure 171/72 mmHg; and SpO2, 92% while using non-rebreather-mask (15 L/min). Physical examination showed a clear breathing sound without a heart murmur. Laboratory examinations revealed metabolic acidosis, elevated lactate (6.5 mmol/L, normal value 0.5–2.2 mmol/L), elevated d-dimer (3747.23 ng/mL, normal value $<$499 ng/mL), normal fibrinogen (293.8 mg/dL, normal value 180–350 mg/dL), elevated NT-BNP (1247 pg/mL), and dynamic cardiac troponin-I elevation (114 pg/mL to 191 pg/mL in four hours, normal range $<$17.5 pg/mL). A contrast-enhanced CT scan of pulmonary arteries revealed a large non-enhancing mass about 67 $\times$ 50 $\times$ 63 mm in size near the right atrium extending up to the inferior vena cava and adjacent hepatic vein (Figs. 2,3,4). The patient was admitted to the cardiovascular intensive care unit (ICU) for further management.

Fig. 2.Coronal section revealed a lesion about 67 $\times$ 50 $\times$ 63 mm in the right atrium.

PA, pulmonary artery; RA, right atrium; LV, left ventricle.

Fig. 3.Sagittal section revealed a poorly enhanced lesion in the right atrium with inferior vena cava extension.

LA/RA, left and right atrium; SVC/IVC, superior/inferior vena cava.

Fig. 4.Axial section revealed a poorly enhanced lesion in the right atrium with inferior vena cava extension.

Transesophageal echocardiography (TEE) performed after ICU admission showed a large heterogenous cauliflower-like mass, 4 $\times$ 6 cm in size, with septated and cavitated lesion occupying the right atrial cavity, compressing the right ventricle (Fig. 5). The differential diagnosis included myxoma, organized thrombus, sarcoma, lymphoma, and metastatic lesions. We initiated Heparin infusion under the tentative diagnosis of intracardiac thrombosis, and surgical intervention was planned for the next day. However, dyspnea and hypoxemia progressed rapidly while the surgeon was discussing the need for intervention with the family. Due to respiratory failure and lactate acidosis, we initiated tracheal intubation, inotropes, and resuscitation 46 hours after admission. Respiratory decompensation with severe metabolic acidosis and multiple organ failure progressed despite medical treatment, and the patient expired 60 hours after admission.

Fig. 5.Transesophageal echocardiography, mid-esophageal.

Ao, aorta; Pa, pulmonary artery.

3. Discussion

Cardiac mass is an unusual condition that can manifest as a variety of clinical symptoms. We report a case of a 72-year-old woman who presented with rapidly progressing right atrial mass extending into the right ventricle, inferior vena cava, and hepatic vein. Atrial masses can be classified into two types: cardiac thrombus and non-thrombus, i.e., tumors. Myxoma usually originates in the left atrium and is the most common primary cardiac tumor. Masses in the right atrium usually originate from metastatic malignancies.

On CT imaging, myxomas usually appear as round masses with a stem, floating randomly or even extending into the ventricle during the cardiac cycle. Atrial thrombosis usually occurs in patients with atrial fibrillation, structural heart disease, or those having an intra-cardiac device, most of which lack stems [1]. However, the differences between myxoma and thrombosis are difficult to distinguish from cardiac ultrasound or computer tomography. This patient did not exhibit any contributing factors, such as atrial fibrillation, structural heart disease, myocardial infarction, or previous heart failure, which indicate a high tendency to form cardiac thrombosis [2]. Other suggested causes of venous thrombosis include implantation of venous access devices, congenital coagulopathies, Behçet’s disease, surgery, malignancy, trauma, pregnancy, obesity, long fly trip, and medication. Our patient did not have any of these signs and risks mentioned above. Torres and Doukky reported a massive obliterative right atrial thrombus in a 51-year-old male who presented with a near-syncope. After undergoing a successful operation, the patient was discharged with Warfarin for a target international normalized ratio of 2.5–3.5 [3]. Cisico et al. [4] reported a calcified thrombosis originating from the right atrium and inferior vena cava. They recommended that surgical removal of the cardiac mass can help achieve both correct diagnosis and treatment to prevent further complications as embolic events or vessel occlusion. Based on the cases and diagnoses discussed so far, we believe that a detailed radiological study is required for diagnosis and surgical intervention. Using the above strategy could be the best course of action for patients diagnosed with intracardiac mass irrespective of the pathology.

Peripheral edema is a frequent symptom in patients with heart failure. Unusually, our patient presented no edema during her two visits to the ED. The mass, primarily located near the right atrium, might interrupt blood flow to the right heart than the left heart.

After reviewing the clinical course of our patient, we concluded that high quality imaging and image analysis is crucial for early diagnosis of cardiac mass. Diagnostic methods such as cardiac echography or contrast-enhanced image studies should have been performed during her first visit to allow for early diagnosis and resection. Several malignancies may show similar cardiac metastasis. However, due to the patient’s critical condition, we did not have enough time to conduct more detailed diagnostic tests.

Author contributions

IHC and RCW designed the study and collect the information about this patient. IHC, LJL, and RCW conducted and analyzed the data. IHC, LJL wrote the original draft. RCW reviewed and revised the manuscript and supervised the study. All authors approved the final manuscript.

Ethics approval and consent to participate

This report was approved by Hualien Tzu Chi Hospital Research Ethics Committee at the moment (CR110-05). Written informed consent was obtained from the son of this patient for the patient’s anonymized information to be published in this article. Data and images were obtained in accordance with the principles outlined in the Declaration of Helsinki.

Acknowledgment

The authors want to thank the family of this patient to agree us to present the condition of this patient, we also thank to Dr. Pau-Yuan Chang for his kindness and enthusiasm on teaching in radiology.

Funding

This research received no specific grant from any funding agency in the public, commercial, or not-for-profit sectors.

Conflict of interest

The authors declare no conflict of interest.

Human rights

Our work does not infringe on any rights of others, including privacy rights, and intellectual property rights. There is no human rights violation in our manuscript.
